Product Applications Solution Process CPU GPU Memory Storage Video Processing HDR Ethernet USB/PCI-e Audio Interface Video Output DVB Video Interface Applications Voice & Audio Processing LCD Interface Peripheral Interface Security Engine Applicable Solutions Video Input ISP Neural Network DTV/ATV PQ Engine SDIO Local Dimming Standards Bluetooth Band Bandwidth Phy Interface Package Spec Wi-Fi Band (Bandwidth) Wi-Fi Antenna Max. Phy Rate

A113D

 		Smart Home,
Smart Home,
28nm
Quad-Core ARM Cortex-A53
2D GFX Engine
16-bit DDR3/4
eMMC 5.0, SLC NAND Flash, SPI NOR/NAND, SD
/
/
10/100/1000 MAC
1x USB 2
 2x PCIe Gen-2
SPDIF-in & out, 8Ch PDM, Multi-channel I2S in & out
/
/
/
Smart audio speaker, Smart home
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

A113L

 		Smart Home
Smart Home
12nm
Dual-core ARM Cortex-A35
/
16-bit DDR3/DDR4
OPI PSRAM interface
SPI NOR/NAND
/
/
/
1x USB 2
Stereo CODEC, SPDIF-in & out, 6Ch PDM, Multi-channel I2S in & out
/
/
/
Smart audio speaker, Smart home
/
/
/
/
/
Dual-core HiFi-4 Acoustic/Audio DSP
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

A113L2

 		Smart Home,
Smart Home,
12nm
Quad-Core ARM Cortex A53
/
16-bit DDR3/3L/4, LPDDR4, Up to DDR3200
eMMC5.1, SLC NAND Flash, SPI NOR/NAND Flash
/
/
10/100/1000M MAC+ 10/100M PHY
/
2x 2 channel PDM, Multi I2S/TDM IN/OUT, SPDIF IN/OUT
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

A113X

 		Smart Home,
Smart Home,
28nm
Quad-Core ARM Cortex-A53
2D GFX Engine
16-bit DDR3/4
eMMC 5.0, SLC NAND Flash, SPI NOR/NAND, SD
/
/
/
1x USB2
SPDIF-in & out, 8Ch PDM, Multi-channel I2S in & out
/
/
/
Smart audio speaker, Smart home
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

A113X2

 		Smart Home,
Smart Home,
12nm
64-bit Quad-Core ARM Cortex-A55
/
32-bit DDR3/3L/4, LPDDR4 Up to DDR2666
eMMC 5.1, SLC NAND, QPI/ SPI NOR/NAND, SD
/
/
10/100/1000M MAC
/
PDM/I2S/TDM DMIC, 3 built-in TDM/I2S ports up to 8-ch input and 16-ch output
/
/
/
Smart Speaker, Soundbar, Conference Microphone, Professional Audio Devices
/
/
/
/
/
HiFi-5 DSP
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

A213Y

 		Smart Home,
Smart Home,
28nm
Quad-Core ARM Cortex A5
Quad-Core ARM Mali-G450
16/32-bit DDR3/3L, LPDDR2/3
eMMC 4.4/4.5, SLC/MLC/TLC NAND Flash, SPI NOR/NAND Flash, SD
1080p60 H.265, H.264 decoding, 1080p30 H.264 encoding
/
/
/
2-channel I2S/PCM input & output
HDMI 1.4b up to 1200P60, Single channel LVDS up to 1366x768, 4-lane MIPI-DSI up to 1920x1200
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

A311D

 		Smart Vision, Smart Home, Digital Signage
Smart Vision, Smart Home, Digital Signage
12nm
Quad-Core ARM Cortex-A73 +Dual-core ARM Cortex-A53
ARM Mali-G52 MP4 (6EE) OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4Kp75 10bit H.265, VP9, AVS2 decoding 4Kp30 H.264 decoding 1080p60 H.265, 1080p30 H.264 encoding
HDR10, HDR10+, HLG, Dolby Vision, TCH PRIME
10/100/1000M MAC + 10/100M PHY
1x USB2 + 1x USB3 / (1x PCIe Gen-2+1x USB2.0)
Stereo DACs, SPDIF-in & out,
8Ch PDM, Multi-channel I2S in & out
4Kp60 HDMI 2.1, CVBS, 4-lane MIPI-DSI
2x TS in, ISO7816
/
Digital signage, Smart home, Video Conference, Edge AI server
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

C302X

 		Smart Vision, Smart Home
Smart Vision, Smart Home
12nm
Dual ARM Cortex-A35
/
Sip 16-bit 128/256MB DDR3
eMMC 5.1, SLC NAND Flash, SPI NOR Flash, SPI NAND Flash
/
/
/
/
/
BT.656 output​, MIPI-DSI
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

C305X

 		Smart Vision
Smart Vision
11nm
2x Cortex-A35
/
32-bit DDR3(L)/DDR4 &LPDDR4 SDRAM
EMMC, SLC Nand, SPI Nor flash, SPI Nand flash
/
/
/
/
2x ADC, 2Ch PDM, Built-in 2x DAC, 2x I2S
/
/
/
Smart Vision
/
/
/
/
/
HiFi-4 audio DSP
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

C308L

 		Smart Vision, Smart Home
Smart Vision, Smart Home
12nm
Dual ARM Cortex-A35
/
32-bit DDR3(L)/DDR4 &LPDDR4
eMMC 5.1, SLC NAND Flash, SPI NOR Flash, SPI NAND Flash
/
/
/
/
/
RGB656/RGB666​, BT.656/BT.1120 output​, MIPI-DSI
/
/
/
/
/
/
/
/
N/A
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

C308X

 		Smart Vision
Smart Vision
12nm
2x Cortex-A55
/
32-bit DDR3(L)/DDR4 &LPDDR4 SDRAM
EMMC, SLC Nand, SPI Nor flash, SPI Nand flash
/
/
/
/
/
/
/
/
Smart vision
/
/
/
/
/
Dual-core HiFi-4 Acoustic/Audio DSP
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S805Y

 		Smart STB
Smart STB
28nm
Quad-Core ARM Cortex-A53
ARM Mali-450 MP3
OpenGL ES2.0
32-bit DDR3/4, LPDDR2/3
eMMC 5.0, NAND Flash, SPI NOR, SD
1080p60 10bit H.265, VP9, H.264 decoding 1080p30 H.264 encoding
HDR10, HLG
10/100 MAC + PHY
2x USB2
Stereo DACs, SPDIF-in & out, Multi-channel I2S in & out
1080p60 HDMI 1.4b, CVBS
1x TS in
/
DVB/OTT/IP STB, Smart TV dongle
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905D

 		Smart STB, Smart Home
Smart STB, Smart Home
28nm
Quad-Core ARM Cortex-A53
ARM Mali-450 MP3
OpenGL ES2.0
32-bit DDR3/3L/4, LPDDR2/3
eMMC 5.0, NAND Flash, SPI NOR, SD
4Kp60 H.265, VP9 P-2 decoding 4Kp30 H.264 decoding 1080p30 H.264 encoding
HDR10, HLG
10/100/1000M MAC + 10/100M PHY
2x USB2
Stereo DACs, SPDIF, Multi-channel I2S in & out
4Kp60 HDMI 2.0b, CVBS
1x TS in, ISO7816
/
DVB/OTT/IP STB, Smart TV dongle, Smart home
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905D3

 		Smart STB, Smart Home, Digital Signage
Smart STB, Smart Home, Digital Signage
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G31 MP2
 OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4Kp75 10bit H.265, VP9, AVS2 decoding
 4Kp30 H.264 decoding 1080p60 H.265, 1080p30 H.264 encoding
HDR10, HDR10+, HLG, Dolby Vision, TCH PRIME
10/100/1000M MAC + 10/100M PHY
1x USB2+ 1x USB3 / (1x PCIe Gen-2+1x USB2.0)
Stereo DACs, SPDIF-in & out,
 8Ch PDM, Multi-channel I2S in & out
4Kp60 HDMI 2.1, CVBS, 4-lane MIPI-DSI
2x TS in, ISO7816
/
Smart home, Digital signage
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905L

 		Smart STB
Smart STB
28nm
Quad-Core ARM Cortex-A53
ARM Mali-450
32-bit DDR3/3L/4,LPDDR2/3
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4K@60fps H.265/AVS2, 4K@30fps: H.264 decoding 1080P@60fps H.265/H.264 encoding
HDR10, HLG
10/100MAC + 10/100 PHY
/
Stereo DACs, SPDIF, PDM, PCM, I2S
4Kp60 HDMI 2.0b, CVBS
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905X

 		Smart STB
Smart STB
28nm
Quad-Core ARM Cortex-A53
ARM Mali-450 MP3
OpenGL ES2.0
16/32-bit DDR3/3L/4, LPDDR2/3
eMMC 5.0, NAND Flash, SPI NOR, SD
4Kp60 H.265, VP9 P-2 decoding 4Kp30 H.264 decoding 1080p30 H.264 encoding
HDR10, HLG
10/100M MAC + 10/100M PHY
2x USB2
Stereo DACs, SPDIF, Multi-channel I2S in & out
4Kp60 HDMI 2.0b, CVBS
/
/
OTT/IP STB, Smart TV dongle, Smart home
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905X2

 		Smart STB
Smart STB
12nm
Quad-Core ARM Cortex-A53
ARM Mali-G31 MP2
OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4Kp75 10bit H.265, VP9, AVS2 decoding
4Kp30 H.264 decoding 1080p60 H.265, 1080p30 H.264 encoding
HDR10, HDR10+, HLG, Dolby Vision, TCH PRIME
10/100/1000M MAC + 10/100M PHY
1x USB2+ 1x USB3 / (1x PCIe Gen-2+1x USB2.0)
Stereo DACs, SPDIF-in & out,
8Ch PDM, Multi-channel I2S in & out
4Kp60 HDMI 2.1, CVBS
2x TS in, ISO7816
/
DVB/OTT/IP STB
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905X3

 		Smart Home
Smart Home
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G31 MP2
 OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4Kp75 10bit H.265, VP9, AVS2 decoding
4Kp30 H.264 decoding 1080p60 H.265, 1080p30 H.264 encoding
HDR10, HDR10+, HLG, Dolby Vision, TCH PRIME
10/100/1000M MAC + 10/100M PHY
1x USB2+ 1x USB3 / (1x PCIe Gen-2+1x USB2.0)
Stereo DACs, SPDIF-in & out,
8Ch PDM, Multi-channel I2S in & out
4Kp60 HDMI 2.1, CVBS
2x TS in, ISO7816
/
DVB/OTT/IP STB
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905X4

 		Smart STB
Smart STB
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G31 MP2
32-bit DDR3/3L/4,LPDDR3/4
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4Kp75 10bit: AV1/H.265/VP9 P-2/AVS2, 4Kp30: H.264 decoding 1080p60 H.265, 1080p30 H.264 encoding
HDR10/10+, HLG,Dolby Vision, TCH PRIME
10/100/1000MAC + 10/100 PHY
1x USB2(OTG) + 1x USB3 or 2x USB2(OTG,HOST) + 1x PCIe-2
Stereo DACs, SPDIF-in & out, 8Ch PDM, 12+Ch I2S in, 12+ch I2S out
4Kp60 HDMI 2.1, CVBS
4xTS in, ISO7816
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905Y2

 		Smart STB
Smart STB
12nm
Quad-Core ARM Cortex-A53
ARM Mali-G31 MP2
OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4Kp75 10bit H.265, VP9, AVS2 decoding
4Kp30 H.264 decoding 1080p60 H.265, 1080p30 H.264 encoding
HDR10, HDR10+, HLG, Dolby Vision, TCH PRIME
-
USB/PCI-e 1x USB2+ 1x USB3 / (1x PCIe Gen-2+1x USB2.0)
Stereo DACs, SPDIF-in & out,
8Ch PDM, Multi-channel I2S in & out
4Kp60 HDMI 2.1
2x TS in, ISO7816
/
DVB/OTT/IP STB, Smart TV dongle
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905Y4

 		Smart STB
Smart STB
12nm
Quad-Core ARM Cortex-A35
ARM Mali-G31 MP2 OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DRAM, DDR4, LPDDR4
eMMC 5.0, SLC NAND Flash, SPI NOR/NAND, SD
4Kx2K@60fps 10bit H.265, AV1, VP9, AVS2 decoding 4Kx2K@30fps H.264 decoding
HDR10+, HDR10, HLG HDR, Dolby Vision
10/100 MAC + PHY
2xUSB 2 (1xHost+1xOTG)
Stereo DACs, SPDIF-in&out, eARC, 8Ch PDM, Multi-channel I2S in&out
4Kp60 HDMI 2.1a, CVBS
/
/
DVB/OTT/IP STB, Smart TV dongle
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S912

 		Smart STB
Smart STB
28nm
Octa-Core ARM Cortex-A53
Multi-core ARM® Mali™-T820 MP3
OpenGL ES3.1
16/32-bit DDR3/3L/4, LPDDR2/3
eMMC 5.0, NAND Flash, SPI NOR, SD
4Kp60 H.265/VP9 decoding 4Kp30 H.264 decoding 1080p60 H.265/H.264 encoding
HDR10, HLG, Dolby Vision
10/100/1000M MAC + 10/100M PHY
3x USB2
Stereo DACs, SPDIF-in & out,
2Ch PDM, Multi-channel I2S in & out
HDMI 2.0b, CVBS
2x TS in, 1x TS out, ISO7816
/
DVB/OTT/IP STB
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S922X

 		Smart STB
Smart STB
12nm
Quad-Core ARM Cortex-A73 +Dual-core ARM Cortex-A53
ARM Mali-G52 MP4 (6EE) OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
4Kp75 10bit H.265, VP9, AVS2 decoding 4Kp30 H.264 decoding 1080p60 H.265, 1080p30 H.264 encoding
HDR10, HDR10+, HLG, Dolby Vision, TCH PRIME
10/100/1000M MAC + 10/100M PHY
1x USB2 + 1x USB3 / (1x PCIe Gen-2+1x USB2.0)
Stereo DACs, SPDIF-in & out,
8Ch PDM, Multi-channel I2S in & out
4Kp60 HDMI 2.1, CVBS, 4-lane MIPI-DSI
2x TS in, ISO7816
/
DVB/OTT/IP STB, Smart home
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T920L

 		Smart TV
Smart TV
28nm
Dual-Core ARM Cortex-A53
ARM Mali-450 MP2
 OpenGL ES2.0
DDR3/3L/4 up to 1GB
eMMC 5.0, SPI NOR, SD
4Kp30 H.265 decoding 1080p60 H.264 decoding
/
10/100M MAC + PHY
3x USB2
Stereo CODEC, SPDIF, I2S, PCM
LVDS, CVBS
/
/
All-in-one smart TV
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T950D4

 		Smart TV
Smart TV
12nm
Quad-Core Cortex-A35
ARM Mali-G31 MP2
32-bit DDR3/3L/4
eMMC 5.0, SLC NAND
2Kp75 10-bit AV1/H.265/VP9/H.264 decoding
HDR10+, HDR10, HLG
10/100M MAC + PHY
3x USB 2.0
Stereo CODEC, PDM x4, I2S-in & out, SPDIF-in & out, PCM
LVDS, CVBS, 2K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T950X

 		Smart TV
Smart TV
28nm
Quad-Core ARM Cortex-A53
ARM Mali-450 MP3
 OpenGL ES2.0
32-bit DDR3/4, LPDDR2/3
eMMC 5.0, SPI NOR, SD
4Kp60 10bit H.265, VP9 decoding 4Kp30 H.264 decoding 1080p30 H.264 encoding
HDR10, HLG
10/100M MAC + PHY
4x USB2
Stereo CODEC, SPDIF-in & out, Multi-channel I2S in & out
LVDS, CVBS
/
/
All-in-one smart TV
/
/
/
/
/
/
/
/
/
/
Yes
/
/
/
/
/
/
/
/
/
/
/
/

T950X4

 		Smart TV
Smart TV
12nm
Quad-Core Cortex-A35
ARM Mali-G31 MP2
32-bit DDR3/3L/4
eMMC 5.0, SLC NAND
2Kp75 10-bit AV1/H.265/VP9/H.264 decoding
HDR10+, HDR10, HLG
10/100M MAC + PHY
3x USB 2.0
Stereo CODEC, PDM x4, I2S-in & out, SPDIF-in & out, PCM
LVDS, CVBS, 2K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T960X

 		Smart TV
Smart TV
28nm
Quad-Core ARM Cortex-A53
ARM Mali-450 MP3
OpenGL ES2.0
32-bit DDR3/4, LPDDR2/3
eMMC 5.0, SPI NOR, SD
4Kp60 10bit H.265, VP9 decoding 4Kp30 H.264 decoding 1080p30 H.264 encoding
HDR10, HLG
10/100M MAC + PHY
4x USB2
Stereo CODEC, SPDIF-in & out, 8Ch PDM, Multi-channel I2S in & out
V-by-1, LVDS, CVBS
/
/
All-in-one smart TV
/
/
/
/
/
/
/
/
/
/
Yes
/
/
/
/
/
/
/
/
/
/
/
/

T962

 		Smart TV
Smart TV
28nm
Quad-Core ARM Cortex-A53
ARM Mali-450 MP3
OpenGL ES2.0
32-bit DDR3/3L/4
eMMC 5.0, SPI NOR, SD
4Kp60 10bit H.265 decoding 4Kp30 H.264 decoding 1080p30 H.264 encoding
HDR10, HLG
10/100M MAC +10/100M PHY
4x USB2
Stereo CODEC, SPDIF, Multi-channel I2S in & out, PCM
CVBS, LVDS, V-by-1
/
/
All-in-one smart TV
/
/
/
/
/
/
/
/
/
/
Yes
/
/
/
/
/
/
/
/
/
/
/
/

T962D4

 		Smart TV
Smart TV
12nm
Quad-Core Cortex-A55
ARM Mali-G31 MP2 OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, DDR2666
eMMC 5.0, SLC NAND Flash
4Kp75 10bit AV1/H.265/VP9 decoding 4Kp60 AVS2 decoding 4Kp30 H.264 decoding
Dolby Vision, HDR10+, HDR10, HLG
10/100/1000M MAC + 10/100M PHY
USB 2.0 x3
Stereo CODEC, SPDIF-in & out, 4Ch PDM, 16Ch I2S in&out
V-by-1, LVDS, CVBS, 4K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T962E2

 		Smart TV
Smart TV
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G31 MP2
OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, SLC NAND Flash, SPI NOR, SD
4Kp75 10bit AV1/H.265/VP9 decoding
4Kp30 H.264 decoding 1080p30 H.264 encoding
Dolby Vision, HDR10+, HDR10, HLG
10/100/1000M MAC + 10/100M PHY
1x USB2, 2x USB3 / (PCIe Gen-2+USB2.0)
Stereo CODEC, SPDIF-in & out, 8Ch PDM, Multi-channel I2S in & out
4Kp60 HDMI 2.1 w/ eARC, CVBS
/
/
Split smart TV, Smart home
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T962X3

 		Smart TV, Digital Signage
Smart TV, Digital Signage
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G31 MP2
 OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, SLC NAND Flash, SPI NOR, SD
4Kp75 10bit AV1/H.265/VP9 decoding
4Kp30 H.264 decoding 1080p30 H.264 encoding
Dolby Vision, HDR10+, HDR10, HLG
10/100/1000M MAC + 10/100M PHY
2x USB2, 1x USB3 / (PCIe Gen-2+USB2)
Stereo CODEC, SPDIF-in & out, 8Ch PDM, Multi-channel I2S in & out
V-by-1, LVDS, CVBS, 4K TCON
/
/
All-in-one smart TV, digital signage, smart projector
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T963

 		Smart TV
Smart TV
12nm
Quad-Core Cortex-A35
ARM Mali-G31 MP2
16/32-bit DDR3/4
eMMC 5.0
4Kp75 10-bit H.265/AVS2, 4Kp30 H.264 decoding
HDR10/10+, HLG
10/100M MAC + PHY
3x USB2.0
Stereo CODEC, PDM x4, I2S-in & out, SPDIF-in & out, PCM
V-by-1, LVDS, CVBS, 4K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T963D4

 		Smart TV
Smart TV
12nm
Quad-Core ARM Cortex A55
ARM Mali-G57MC1
48-bit DDR3/3L/4
eMMC 5.1, SLC NAND Flash
4Kx2K@60 fps AV1/ H.265/VP9/AVS2 decoding 4Kx2K@30 fps H.264 decoding 1080P@30fps H264 encoding
Dolby Vision, HDR10+, HDR10, Prime, HLG
10/100/1000M MAC+ 10/100M PHY
/
Stereo CODEC, PDM x4, SPDIF, PCM, built-in HW EQ/DRC
V-by-1, LVDS, CVBS, 4K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T965D4

 		Smart TV
Smart TV
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G52MP2(2EE)
64-bit DDR3/3L/4
eMMC 5.0, SLC NAND Flash
8Kx4K@30fps+4Kx2K@60fps AV1/H.265/VP9 decoding 4Kx2K@60fps AVS2 decoding 4Kx2K@30fps H.264 decoding 1080@30fps H.264 encoding
Dolby Vision, HDR10+, HDR10, HLG
10/100/1000M MAC+ 10/100M PHY
/
Stereo CODEC, PDM x8, SPDIF, PCM, built-in HW EQ/DRC
V-by-1, LVDS, CVBS, 4K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T966

 		Smart TV
Smart TV
28nm
Quad-Core ARM Cortex-A53
ARM Mali-T830 MP2
OpenGL ES3.1
64-bit DDR3/3L
eMMC 5.0, SPI NOR, SD
4Kp60 10bit H.265 decoding 4Kp30 H.264 decoding 1080p30 H.264 encoding
HDR10, HLG
10/100/1000M MAC
3x USB2 + 1x USB3
Stereo CODEC, SPDIF, I2S, PCM
4Kp60 HDMI 2.0b, CVBS
/
/
Split smart TV, smart projector
/
/
/
/
/
/
/
/
/
/
Yes
/
/
/
/
/
/
/
/
/
/
/
/

T968

 		Smart TV
Smart TV
28nm
Quad-Core ARM Cortex-A53
ARM Mali-T830 MP2
 OpenGL ES3.1
64-bit DDR3/3L
eMMC 5.0, SPI NOR, SD
4Kp60 10bit H.265 decoding 4Kp30 H.264 decoding 1080p30 H.264 encoding
HDR10
10/100/1000M MAC
3x USB2 + 1x USB3
Stereo CODEC, SPDIF, Multi-channel I2S in & out, PCM
CVBS, LVDS
/
/
All-in-one smart TV, Smart projector
/
/
/
/
/
/
/
/
/
/
Yes
/
/
/
/
/
/
/
/
/
/
/
/

T972

 		Smart TV, Digital Signage
Smart TV, Digital Signage
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G31 MP2
 OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
32-bit DDR3/3L/4, LPDDR3/4
eMMC 5.0, SLC NAND Flash, SPI NOR, SD
8Kp24 10bit H.265/VP9 decoding
4Kp60 AVS2 decoding
4Kp30 H.264 decoding
HDR10+, HDR10, HLG
10/100/1000M MAC + 10/100M PHY
3x USB2
Stereo CODEC, SPDIF-in & out, 8Ch PDM, Multi-channel I2S in & out
V-by-1, LVDS, CVBS, 4K TCON
/
/
All-in-one smart TV, Smart projector
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

T982

 		Smart TV, Smart Vision
Smart TV, Smart Vision
12nm
Quad-Core ARM Cortex-A55
ARM Mali-G52 MP2 OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0
64-bit DDR3/4
eMMC 5.0, SLC NAND Flash
8Kp30 10bit H.265/VP9 decoding 4Kp60 AVS2 decoding 4Kp30 H.264 decoding
HDR10+, HDR10, HLG, Dolby Vision
10/100/1000M MAC + 10/100M PHY
3x USB 2.0，1x USB 3.0 / (PCIe Gen-2+USB2.0)
Stereo CODEC, SPDIF-in & out, 8Ch PDM, Multi-channel I2S in & out
V-by-1, LVDS, CVBS, 4K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

V901D

 		Smart TV, Smart Vision
Smart TV, Smart Vision
12nm
Quad-Core Cortex-A55
ARM Mali-G31 MP2
32-bit DDR3/4, LPDDR3/4
eMMC 5.0, SLC NAND
4Kp60 10bit: AV1/H.265/VP9 P-2/AVS2, 4Kp30: H.264 decoding 1080p30 H.264 encoding
Dolby Vision, HDR10/10+,HLG, Prime HDR
10/100/1000MAC w/ AVB + 10/100 PHY
1x USB2(OTG) + 1x USB3 or 2x USB2(OTG,HOST) + 1x PCIe-2
Stereo DACs, SPDIF-in & out, 8Ch PDM, I2S-in & out
V-by-1, LVDS, CVBS, 4K TCON
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

W155S1

 		Smart STB, Smart TV, Smart Home,
Smart STB, Smart TV, Smart Home,
22nm
RISC-V x 2
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
IEEE 802.11 a/b/g/n/ac compliant
BT5.0, BR/EDR/BLE, LE Long Range
2.4GHz/5GHz dual-band
VHT20, VHT40, VHT80
433Mbps
SDIO3.0/UART/PCM
6x6 QFN52
/
/
/
/

W155S2

 		Smart STB, Smart TV, Smart Home,
Smart STB, Smart TV, Smart Home,
22nm
RISC-V x 2
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
SDIO3.0/UART/PCM
QFN52 6mmx6mm
Wi-Fi 5 (802.11 a/b/g/n/ac) + BT 5.0
/
/
/

W155U1

 		Smart STB, Smart TV, Smart Home,
Smart STB, Smart TV, Smart Home,
22nm
RISC-V x 2
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
USB2.0/PCM
QFN52 6mmx6mm
Wi-Fi 5 (802.11 a/b/g/n/ac) + BT 5.0
/
/
/

W265P1

 		Smart STB, Smart TV, Smart Home,
Smart STB, Smart TV, Smart Home,
22nm
RISC-V x 2
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
PCIe2.1 + UART/PCM
QFN76 8mmx8mm
Wi-Fi 6 ​(IEEE 802.11 a/b/g/n/ac/ax compliant)​ + BT 5.4 Combo
/
/
/

W265S1

 		Smart STB, Smart TV, Smart Home, Home Connectivity, Smart Audio
Smart STB, Smart TV, Smart Home, Home Connectivity, Smart Audio
22nm
RISC-V x 2
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
SDIO3.0 / UART / PCM
QFN76 8mmx8mm
Wi-Fi 6 ​(IEEE 802.11 a/b/g/n/ac/ax compliant)​ + BT 5.4 Combo
/
/
/

W265U1

 		Smart STB, Smart TV, Smart Home, Home Connectivity, Smart Audio
Smart STB, Smart TV, Smart Home, Home Connectivity, Smart Audio
22nm
RISC-V x 2
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
USB2.0/PCM
QFN76 8mmx8mm
Wi-Fi 6 (802.11 a/b/g/n/ac/ax) + BT 5.4 Combo
/
/
/

S905X5M

 		Smart STB, Smart TV, Smart Home, Home Connectivity, Smart Audio
Smart STB, Smart TV, Smart Home, Home Connectivity, Smart Audio
6nm
Quad-Core Cortex-A55
ARM G310 V2
16/32-bit DDR4/LPDDR4 up to 4GB
eMMC 5.2 w/ HW CQ & inline encrypt, SLC/QSPI NAND, SD
4Kp75 10bit: AV1,H.265,VP9 P-2,AVS2 4Kp30: H.264 Decoding; 1080p30 H.264 Encoding
HDR10/10+, HLG, Dolby Vision (Opt.), TCH PRIME
10/100/1000 MAC + 10/100 PHY
2x USB2(OTG,HOST), USB-C CC
/
HDMI 2.1b 4Kp60 output w. ALLM, eARC, QMS, VRR, QFT, SBTM. CVBS
2x TS(S) in, ISO7816
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S928X

 		Smart STB, Smart TV, Smart Home, Digital Signage
Smart STB, Smart TV, Smart Home, Digital Signage
12nm
ARM Cortex-A76+Quad-Core ARM Cortex-A55
ARM Mali-G57 MC2, 4K GUI OpenGL ES 3.2, Vulkan 1.2 and OpenCL 2.0
64-bit DDR4, LPDDR4/4X, DDR4266
eMMC 5.1, SLC NAND Flash
8Kx4K@60fps 10bit H.265, AV1, VP9, AVS3, AVS2 decoding 4Kx2K@30fps H.264 decoding 4K@60fps H.265/H.264 encoding
HDR 10/10+, HLG, Dolby Vision, HDR Vivid
10/100/1000 MAC
2xUSB 2 (OTG, HOST)+1xUSB 3+1xPCIe-2
Stereo DACs, SPDIF-in&out, eARC, 8Ch PDM, Multi-channel I2S in&out
8Kp60 HDMI 2.1a (eARC, VRR, ALLM, QMS, QFT, DSC1.2, SBTM), HDCP 2.2/2.3
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

S905X5

 		Smart STB, Smart TV, Smart Home, Digital Signage
Smart STB, Smart TV, Smart Home, Digital Signage
6nm
Quad-Core ARM V9 Cortex-A510
ARM G310 V5
32-bit LPDDR4/4x, LPDDR5 Up to 16GB
eMMC 5.2 w/ HWCQ & inline encrypt, SD
2x4Kp60 10b: H.266/VVC, H.265, AV1, VP9 P-2, AVS3 4Kp60: H.264 Decoding 4Kp60 H.265, H.264 Encoding
/
10/100/1000 MAC + 10/100 PHY
1xUSB2.0(OTG),1x USB3, USB-C CC, 1xPCIe-3
/
HDMI 2.1b 4Kp60 output w. ALLM, eARC, QMS, VRR, QFT, SBTM
4x TS in(4S or 1P+1S), ISO7816
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/

Applications

Smart STB

Smart TV

Digital Signage

Smart Vision

Smart Home

Smart Audio

Automation

Home Connectivity

Smart STB

The next generation home entertainment center brings unprecedented multimedia experience to the users

LEARN MORE

Smart TV

The next generation home entertainment center brings unprecedented multimedia experience to the users
LEARN MORE

Digital Signage

The next generation home entertainment center brings unprecedented multimedia experience to the users
LEARN MORE

Smart Vision

The next generation home entertainment center brings unprecedented multimedia experience to the users
LEARN MORE

Smart Home

The next generation home entertainment center brings unprecedented multimedia experience to the users
LEARN MORE

Smart Audio

LEARN MORE

Automation

LEARN MORE

Home Connectivity

LEARN MORE

Technological edge

AI Technologies

AI Technologies

Video and Display Technologies

Video and Display Technologies

Audio Technologies

Audio Technologies

Voice and Smart Interaction

Voice and Smart Interaction

Digital Interface Technologies

Digital Interface Technologies

Video Coding Technologies

Video Coding Technologies

Operating Systems

Operating Systems

Cryptographic Technologies

Cryptographic Technologies

Wireless Communication

Wireless Communication
